Porous PTFE Sheet YS9006P

Porous PTFE Sheet, release sheet that can allow air circulation

Porous PTFE Sheet has a higher porosity than most Teflon coated fabrics, and this fabric combines fiberglass with lower content of PTFE coating.

This Porous PTFE fabric is used in applications which need airflow pass throw the fabric under pressure (air circulation for drying and curing processes), normal applications including casting sheets for uncured elastomers, vacuum bag bleeder cloth for composite molding in the manufacturing of composite aircraft components.

Unlike PTFE premium series, it is more flexible, much stronger and can be wrapped around curved shapes.



Porous PTFE Sheet



After many years development, Youngsun offering Porous series with balanced PTFE content and porosity.

With high porosity surface, this Porous PTFE Sheet allow air pass the fabric during the production such as vacuum bag bleeder cloth, which allow products to cure and out gas through fabric.

In the meantime, PTFE content will still ensure easy release and high tensile strength. Youngsun will balance these two properties.



Porous PTFE Sheet, standard width is 1000mm

Porous PTFE Sheet, standard width is 1000mm



Applications of Porous PTFE coated fabrics



Because of their unique properties, these fabrics are excellent for using in a wide range of applications, from the manufacture of polymers to a release medium for composite molding process.



Applications of Porous PTFE Sheet:



  Aerospace, Communications & Milltary, Composite mold release in vacuum bag, or use as release sheets for fabricating glass-resin structures.

  Polymer Processing: Manufacture of silicone rubber sheets, Curing rubber and plastic foams and sponge.

  Insulation and protection.

  Seperation materials.

  Drying painted or lacquered products.

  Release sheet for heat sealing machines



Porous Teflon Sheet

Porous Teflon Sheet



Specifications of Porosity PTFE fabric



ProductProduct CategoryCoating
PTFE GLASS FABRICPOROUS SERIESPTFE



PropertiesMetricImperial
Standard width
Please ask for other widths
1000 mm39.5 inches
Thickness0.06 mm0.0024 inches
Coated weight66 g/m² 1.95 oz/yd²
PTFE content27 %27 %
Porosity20-100 cfm20-100 cfm
Tensile strength160 N/cm Warp91.5 lbs/inches Warp
146 N/cm Fill83.5 lbs/inches Warp
Temperature resistance-73 to +260 °C-100 to +500 °F
Click here to download technical data sheet of YS9006P-ESONE
