Pump Insulation Covers, Made with Silicone & PTFE coated fabric for insulation blanket.

Pump Insulation Covers, made of PTFE or Silicone impregnated on both sides or one side fiberglass fabrics. Due to this insulated fabric is anti-aging, anti-environment, anti-corrosion, non stick and heat resistant. So it is used for the outer protection for the insulation covers. And the working temperature of PTFE coated fabric is up to 600F, the maximum temperature of silicone impregnated fabric is 500F.



What is Pump Insulation Covers?



Youngsun’s pump insulation covers are custom-created by designers who know exactly what to consider in making the highest-quality, best-fitting removable blankets for each pump.



And Youngsun’s Silicone impregnated(coated) fabric, is the best Anti-aging, Antiseptic, Heat-resistant, weather resistant and soft insulator, which is used to make the outside jacket for the pump insulation system.

Youngsun’s YS9038HD is PTFE impregnate(coated) fabric, which has higher heat-resistant property than Silicone coated fabric, so it is used for insulation system which need higher temperature and harder surface.



All the basic fiberglass is satin weaved, which ensure the highest tensile strength of the covers(blankets), and Silicone & PTFE coating is flexible in order for making blankets into any different shapes and sizes.



Pump Insulation Covers

Pump Insulation Covers



Why use 17 oz Silicone & PTFE coated fiberglass fabric for Pump Insulation Covers.



PTFE fabric Operating at -94°F to 600°F

Silicone fabric Operating at -67°F to 500°F



– flame resistant

– Environmental resistant

– Chemical resistant

– UV resistant

– Almost smokeless

– Non-stick

– Weather resistant

– Heat resistant



Removable insulation covers

Removable insulation covers



Removable insulation jacket

Removable insulation jacket



The Data sheet of Valve Insulation Covers



Youngsun could make the thermal insulation jackets into Gray, White, Yellow, Black or any other colors.

And the Silicone & PTFE fabric could be coated on one side or both side.



For 17 oz Silicone Impregnated Fiberglass Fabric, the weight is 17.5 oz/sy ± 10%(595 g/m2 ± 10%), and thickness is 0.018″ ± .001″(0.457 mm ± .025 ), the model number is YS5045



ProductProduct CategoryCoating
SILICONE RUBBER
COATED GLASS FABRIC
SILICONE BOTH SIDESILICONE RUBBER



17.5 oz Silicone Impregnated Fiberglass Fabric YS5045
PropertiesMetricImperial
Basic FabricSatin weaved fiberglassSatin weaved fiberglass
CoatingBoth sideBoth side
Standard width
Please ask for other widths
1500 mm60 inches
Coated Weight595 g/m²17.5 oz/yd²
Thickness0.457 mm0.018 inches
Tensile strengthWarp 2679 N/5cm300 lbs/inches
Fill 2009 N/5cm225 lbs/inches
Mullen Burst420 N/cm²600 psi
Flame ResistantChar Length 0.159 cm maxChar Length 1/16 inch max
Afterglow 1 second maxAfterglow 1 second max
Flame Out 1 second maxFlame Out 1 second max
Temperature resistance-54°C to +260°C-67°F to +500°F
Tear Strength22.68 kgWarp- 50 lbs
22.68 kgFill- 50 lbs
ColorGray/White/Yellow/Black/RedGray/White/Yellow/Black/Red



Click here to access the data sheet of YS9038HD-ESONE and YS9040HD-ESONE.



For One side PTFE impregnated fabric(YS9038HD), the weight would be 16.5 oz/sy ± 10%(560 g/m2), and thickness is 0.016″  ± 10% (0.38mm)

For Both side PTFE impregnated fabric(YS9040HD), the weight would be 18 oz/sy ± 10%(650 g/m2), and thickness is 0.018″ ± .001″ (0.40mm)



Thermal insulation blanket

Thermal insulation blanket



Application for Pump Insulation Covers



Removable Insulation Jackets are designed for Pumps, pipeline, valves, freeze protection and so on.

And Different color is for different application, like Yellow insulation jacket is for Gas, Oil and Steam value, pumps and so on.





Pump Insulation Covers could also be used for making Antiseptic Insulation Tent, which could be used to store chemicals(especially for flammable and combustible chemicals), or easy-corrosive, hazardous article.



Antiseptic Insulation Tent

Antiseptic Insulation Tent
