Application in the Magnet Industry

In the production of permanent magnets, PTFE‑coated Kevlar fabric is widely used to manufacture conveyor belts for magnetic separation processes.

During magnetic separation, mixed powders containing both magnetic and non‑magnetic particles are transported across magnetic rollers. The black antistatic PTFE‑coated aramid conveyor belts provide:

• A durable, high‑strength base to carry fine powders without stretching.
• A non‑magnetic, PTFE surface that does not interfere with magnetic fields.
• An antistatic finish to minimize static buildup during fine powder handling.
• An easy‑to‑clean, non‑stick surface that prevents powder accumulation and cross‑contamination.

Why PTFE Coated Kevlar Belt?

In the magnetic separation stage:

• Mixed powder feed falls onto the moving conveyor belt.
• As the belt carries the material across magnetic rollers, magnetic particles adhere to the drum while non‑magnetic particles fall off naturally.
• The PTFE‑coated Kevlar belt provides a smooth, stable, and neutral transport surface, ensuring precise particle separation.
• Its non‑stick property prevents powder build‑up around the drum and splitter, enhancing both efficiency and consistency.

The magnet manufacturing process demands materials that can perform reliably under stringent mechanical, thermal, and magnetic conditions. PTFE coated Kevlar belt meet these requirements by delivering strength, durability, non‑magnetic neutrality, and superior non‑stick properties. For manufacturers looking to optimize separation efficiency and overall process stability, these belts present a proven and cost‑effective solution.

In ESONE, you can get the durable tortilla press belting and reliable service!

With the special formula and construction of the Modified PTFE fabric for tortilla industry, the output of customer’s product will be increased and the cost for production will be reduced, because of the excellent long lasting non stick surface and high mechanical strength of ESONE belts.

The quality of ESONE Teflon belt is better and better due to the increasingly customer’s demand in a more non stick surface, more oil permeation resistance, better heat transfer, stronger abrasion resistance and a superior dimensional stability in order to resist the repetitive contact with heat press.

Let’s help to keep your production lines running continuously smooth!

Click here to know TDS of PTFE modified coated fabric!

Conductive PTFE Belt YS9037BJ, 0.37mm Anti-static release sheet & belt.

Anti-static PTFE Fiberglass Fabric is coated with specially formulated black PTFE, these fabrics eliminate static electricity during operation,

Static can be created by friction or other connection, it will collect electric and dust which may destroy electrical component parts, and it will affect the release due to the electrostatic adsorption.

This conductive PTFE coating fiberglass fabric offers excellent thermal conductivity to dissipate surface static, it is widely used in apparel, electron industry as conveyor belts or release sheet.

• Easy to release, non stick surface
• Heat resistant to 500F
• Dimensional stability
• Chemical resistance
• Excellent belting material
• Anti-static, surface resistance is 10^7 to 10^5 OHMS/m²

Properties	Metric	Imperial
Standard width Please ask for other widths	1000, 1250, 1500, 2000, 2600 mm	39.5, 49.3, 59.1, 78.8, 102.4 inches
Thickness	0.37 mm	0.015 inches
Coated weight	730 g/m²	21.5 oz/yd²
PTFE content	60 %	60 %
Surface resistance	10^7 to 10^5 OHMS/m²	10^7 to 10^5 OHMS/m²
Tensile strength	540 N/cm Warp	308 lbs/inches Warp
	508 N/cm Warp	290 lbs/inches Fill
Temperature resistance	-73 to +260 °C	-100 to +500 °F

Click here to download the TDS of YS9037BJ-ESONE

ESONE conductive Teflon belt YS9037BJ is widely used as non stick release belt in garment fusing machines, due to the excellent non stick surface and high tensile strength of YS9037BJ, ESONE conductive PTFE belt has high performance and long lifetime.

Thermal lamination is a typical process for producing lightweight and high performance composited material in automotive industry.

ESONE PTFE release fabric is a important aid for the lamination operations of decorative material, organo sheet, molten polymers, adhesives and others. These PTFE coated fabric is used as release sheet or conveyor belt due to the excellent temperature resistance, abrasion resistance and easy release surface. ESONE release solutions will ensure the excellent surface of finish product and maximum the output & machine productivity.

ESONE defect free and smooth PTFE coated fabric offer long lasting release property, we are your reliable partner for high performance product.

What can be made by using ESONE PTFE coated fabric

• Dashboards
• Door Carrier
• Door Wells
• Glove Compartments
• Parcel Shelves
• NVH Parts

ESONE Teflon coated glass cloth are a perfect solution for the rubber extrusion and curing line. Our product widely used in the manufacture of rubber profiles, ESONE PTFE belts can continuous working below 260°C and offer excellent release during curing and cooling of PVC, PU, PE or others.

The non stick surface means that nothing will be left on the Teflon belt, this belt will transfer rubber through the microwave oven or electric oven for curing process and the rubber will has excellent smooth surface.

[contact-form-7]

PTFE coating fiberglass fabric YS9025BJ, 0.25mm Anti-static release sheet & belt.

Anti-static PTFE Fiberglass Fabric is coated with specially formulated black PTFE, these fabrics eliminate static electricity during operation,

Static can be created by friction or other connection, it will collect electric and dust which may destroy electrical component parts, and it will affect the release due to the electrostatic adsorption.

This conductive PTFE coating fiberglass fabric offers excellent thermal conductivity to dissipate surface static, it is widely used in apparel, electron industry as conveyor belts or release sheet.

• Easy to release, non stick surface
• Heat resistant to 500F
• Dimensional stability
• Chemical resistance
• Excellent belting material
• Anti-static, surface resistance is 10^7 to 10^5 OHMS/m²

Properties	Metric	Imperial
Standard width Please ask for other widths	1000, 1250, 1500, 2000, 2600 mm	39.5, 49.3, 59.1, 78.8, 102.4 inches
Thickness	0.25 mm	0.0098 inches
Coated weight	530 g/m²	15.63 oz/yd²
PTFE content	62 %	62 %
Surface resistance	10^7 to 10^5 OHMS/m²	10^7 to 10^5 OHMS/m²
Tensile strength	460 N/cm Warp	263 lbs/inches Warp
	400 N/cm Warp	229 lbs/inches Fill
Temperature resistance	-73 to +260 °C	-100 to +500 °F

Click here to download the TDS of YS9025BJ-ESONE

In order for highly increasing the non stick and lifetime property, ESONE is also modifying the YS9025BJ, click the button to know more about the YS9025BJ-M-ESONE

ESONE Teflon coated glass cloth is widely used as non stick release sheet in PV module vacuum lamination process, or used as conveyor belts for half cell welding machines. Since PV industry has very high request for the smooth surface, lifetime, mechanical and release property of PTFE coated fabric, so the performance of Teflon coating fabric will be a critical factor for maximum the production up time, and increasing the quality of the module.

Thermal lamination is a typical process for producing lightweight and high performance composited material in automotive industry.

ESONE PTFE coating fiberglass fabric is a important aid for the lamination operations of decorative material, organo sheet, molten polymers, adhesives and others. These PTFE coated fabric is used as release sheet or conveyor belt due to the excellent temperature resistance, abrasion resistance and easy release surface. ESONE release solutions will ensure the excellent surface of finish product and maximum the output & machine productivity.

ESONE defect free and smooth PTFE coated fabric offer long lasting release property, we are your reliable partner for high performance product.

What can be made by using ESONE PTFE coated fabric

• Dashboards
• Door Carrier
• Door Wells
• Glove Compartments
• Parcel Shelves
• NVH Parts

Carbon Fiber Composites in automotive industry like doors, side mirror, hoods and life-gates are the easiest options to reduce the weight of vehicle, and other significant options such as seats, under-tray, instruments, engine covers is expected to nearly double usage from 2015 to 2020.

ESONE PTFE coating fiberglass fabric is used as release sheet or release belt in the production of carbon fiber prepreg, such as heat press processing, vacuum bagging system and others.

By using PTFE bleeder cloth, the carbon fiber prepreg will have a excellent shiny surface or a textured surface, for example, PTFE coated fabric industrial series is used for the manufacturing of carbon fiber sports equipment in order to increase the skin friction.

ESONE Teflon coated glass cloth are a perfect solution for the rubber extrusion and curing line. Our product widely used in the manufacture of rubber profiles, ESONE PTFE belts can continuous working below 260°C and offer excellent release during curing and cooling of PVC, PU, PE or others.

The non stick surface means that nothing will be left on the Teflon belt, this belt will transfer rubber through the microwave oven or electric oven for curing process and the rubber will has excellent smooth surface.

FPCB is flexible printed circuit boards, which is a modern flexible electronic equipment types, using in printer, phones, camera and home devices.

ESONE Teflon coated glass cloth is the product of choice for CVL lamination, due to the excellent release property, high dielectric strength and mechanical strength.

ESONE PTFE cloth YS9023BJ is also used as release belt for tissue manufacturing, due to the excellent non stick surface and heat resistant property, this release belt is used for easy release in the sealing packaging of tissue box.

[contact-form-7]

PTFE coated glass clothes YS9023BJ, 0.23mm Anti-static release sheet & belt.

Anti-static PTFE Fiberglass Fabric is coated with specially formulated black PTFE, these fabrics eliminate static electricity during operation,

Static can be created by friction or other connection, it will collect electric and dust which may destroy electrical component parts, and it will affect the release due to the electrostatic adsorption.

This conductive PTFE fabric offers excellent thermal conductivity to dissipate surface static, it is widely used in apparel, electron industry as conveyor belts or release sheet.

• Easy to release, non stick surface
• Heat resistant to 500F
• Dimensional stability
• Chemical resistance
• Excellent belting material
• Anti-static, surface resistance is 10^7 to 10^5 OHMS/m²

Properties	Metric	Imperial
Standard width Please ask for other widths	1000, 1250, 1500, 2000, 2600 mm	39.5, 49.3, 59.1, 78.8, 102.4 inches
Thickness	0.23 mm	0.0091 inches
Coated weight	500 g/m²	14.75 oz/yd²
PTFE content	60 %	60 %
Surface resistance	10^7 to 10^5 OHMS/m²	10^7 to 10^5 OHMS/m²
Tensile strength	420 N/cm Warp	240 lbs/inches Warp
	360 N/cm Warp	205 lbs/inches Fill
Temperature resistance	-73 to +260 °C	-100 to +500 °F

Click here to download the TDS of YS9023BJ-ESONE

ESONE PTFE coated glass clothes is widely used as non stick release sheet in PV module vacuum lamination process, or used as conveyor belts for half cell welding machines. Since PV industry has very high request for the smooth surface, lifetime, mechanical and release property of PTFE coated fabric, so the performance of PTFE coating fabric will be a critical factor for maximum the production up time, and increasing the quality of the module.

Thermal lamination is a typical process for producing lightweight and high performance composited material in automotive industry.

ESONE PTFE release fabric is a important aid for the lamination operations of decorative material, organo sheet, molten polymers, adhesives and others. These PTFE coated fabric is used as release sheet or conveyor belt due to the excellent temperature resistance, abrasion resistance and easy release surface. ESONE release solutions will ensure the excellent surface of finish product and maximum the output & machine productivity.

ESONE defect free and smooth PTFE coated fabric offer long lasting release property, we are your reliable partner for high performance product.

What can be made by using ESONE PTFE coated fabric

• Dashboards
• Door Carrier
• Door Wells
• Glove Compartments
• Parcel Shelves
• NVH Parts

Carbon Fiber Composites in automotive industry like doors, side mirror, hoods and life-gates are the easiest options to reduce the weight of vehicle, and other significant options such as seats, under-tray, instruments, engine covers is expected to nearly double usage from 2015 to 2020.

ESONE PTFE coated fabric is used as release sheet or release belt in the production of carbon fiber prepreg, such as heat press processing, vacuum bagging system and others.

By using PTFE bleeder cloth, the carbon fiber prepreg will have a excellent shiny surface or a textured surface, for example, PTFE coated fabric industrial series is used for the manufacturing of carbon fiber sports equipment in order to increase the skin friction.

ESONE PTFE coated glass clothes are a perfect solution for the rubber extrusion and curing line. Our product widely used in the manufacture of rubber profiles, ESONE PTFE belts can continuous working below 260°C and offer excellent release during curing and cooling of PVC, PU, PE or others.

The non stick surface means that nothing will be left on the PTFE belt, this belt will transfer rubber through the microwave oven or electric oven for curing process and the rubber will has excellent smooth surface.

ESONE PTFE cloth YS9023BJ is also used as release belt for tissue manufacturing, due to the excellent non stick surface and heat resistant property, this release belt is used for easy release in the sealing packaging of tissue box.

FPCB is flexible printed circuit boards, which is a modern flexible electronic equipment types, using in printer, phones, camera and home devices.

ESONE PTFE coated glass cloth is the product of choice for CVL lamination, due to the excellent release property, high dielectric strength and mechanical strength.

[contact-form-7]

PTFE coated glass fabric YS9013BJ, which is non stick and conductive (anti-static)!

Anti-static PTFE Fiberglass Fabric is coated with specially formulated black PTFE, these fabrics eliminate static electricity during operation,

Static can be created by friction or other connection, it will collect electric and dust which may destroy electrical component parts, and it will affect the release due to the electrostatic adsorption.

This conductive PTFE fabric offers excellent thermal conductivity to dissipate surface static, it is widely used in apparel, electron industry as conveyor belts or release sheet..

• Easy to release, non stick surface
• Heat resistant to 500F
• Dimensional stability
• Chemical resistance
• Anti-static, surface resistance is 10^7 to 10^5 OHMS/m²

Anti static PTFE fabric YS9013BJ is also used on TFT-LCD module and PDP module process, especially in ACF bonding process of TFT-LCD module, this fabric’s function is shock-absorber of bonding tool, eliminate static electricity during operation and protecting glass panel from breaking damage cause by particle and unbalance of PCB size.

Conductive Teflon fabric YS9013BJ is widely used in the heat release industry, any impurity which will stick to the plate will be removed easily, by using this non stick sheet, the plate will be always clean.

This heat release processing is applying to heat transfer press machines, shoemaking industry and others.

ESONE conductive PTFE coated glass fabric is used for electrical insulation such as aerospace wire wrapping and electrical coil and phase insulation.

This Teflon fabric is also used as linings for the coils of superconducting magnets in order for reducing noise and vibration.

ESONE conductive PTFE coated glass fabric YS9013BJ is generally used for making Anti-static Teflon adhesive tape, with the heat resistant silicone pressure adhesive on the back, this Teflon tape can stick to molding or any other places for easy release and heat & chemical resistance.

[contact-form-7]

PTFE cloth YS9004AJ is the thinnest fabric in premium series, the coating process is difficult because the basic fiberglass is almost transparent and light weight like feather, and the final 0.04mm PTFE fabric is also almost transparent as you can see the other side through Teflon fabric.

In some applications which have high request for Teflon fabric, the thinner PTFE fabric can reach, the effect will be better. But it is difficult to manufacture thin PTFE fabric since the basic fabric is easy to be damaged during coating.

And in order to offer thin but long lasting Teflon coated cloth, ESONE is using special coating process and formula to reach customer’s request.

ESONE premium series PTFE cloth has following properties.

• Excellent non stick surface
• High PTFE content, easy to be laminated
• Good mechanical strength
• Outstanding dielectric strength
• Great dimensional stability
• Resist to almost all chemical

Click here to download the spec of YS9004AJ-ESONE

Find more PTFE coated fabric premium series

Because of the superior property of PTFE fabric, ESONE PTFE coated fabric is used as mold release sheet for aerospace industry, packaging industry, pharmaceuticals industry and others.

YS9004AJ is a excellent release solution for precision components due to the light weight and excellent surface.

By lowing the PTFE content but using same fiberglass, this material can be used as porous fabric for the curing, heat-pressing process of composited material, such as vacuum bagging system and so on.

ESONE PTFE cloth YS9004AJ is used in a wide range of electronic applications, such as Copper Clad Laminate(CCL) manufacturing, FPCB manufacturing, LCD conductive film bonding, cable wrapping and others.

Due to the excellent dielectric strength, easy release surface, outstanding dimensional stability and durability in heat, flame resistant and great mechanical strength, electromagnetic solenoids benefit from ESONE long lasting and high performance product.

PTFE porous sheet has good non stick property while maintain the porous property of fabric. And PTFE porous sheet YS9040P has high tensile strength since ESONE is using satin weaved fiberglass fabric as basic material, this porous fabric is widely use in flooring industry, carbon fiber composited industry, aerospace industry and others.

Porosity and non stick surface is two contradictory property in manufacturing PTFE porous fabric, if too much PTFE content, then the porosity will be reduced, on the contrary, the porosity will be increased if lower PTFE content, so it is very important to find the balance to offer best product for customer’s applications.

What’s more, PTFE content also affect the mechanical strength of PTFE fabric, it is because the strength of fiberglass will be reduced when coating PTFE in high temperature, so more times coating, then the strength will be weeker. In this case, ESONE is using special formula and coating ways to maintain high mechanical strength, in order to offer long lasting PTFE porous sheet.

ESONE high tensile porous Teflon sheet is the reliable partner for your application.

YS9040P has higher mechanical strength than common porous fabric because of the different weaving way of fiberglass.

Click here to download the spec of YS9040P-ESONE

Without doubt, carbon fiber laptop is the lightest laptop in the world, this material can be used to build race cars, aircraft, road bike, sports equipment, musical instruments and many other things.

Comparing to aluminum, carbon fiber composite is much more strong and stiff while aluminum is a soft metal, carbon fiber has a lower density than aluminum also, it is commonly used in military and aircraft industry to meet the extreme high demanding request.

YS9040P is used as release sheet for carbon fiber composited, in order to resist the continuously high pressure and high temperature while maintain the easy release surface.

Click here to know more about this application

Luxury Vinyl Tile is a fast growing market which is famous because of the durability and aesthetic appeal. It has many competitive properties than traditional flooring options such as ceramic tile and wooden flooring.

The LVT base layer is formed through a heat and high pressure lamination of PVC crumb and glass skrim. YS9040P PTFE porous sheet is a best release sheet for LVT industry, since Teflon porous fabric is heat resistant, chemical resistant and is porous during PVC melting process.
