teflon adhesive with release paper

/, PTFE Adhesive, PTFE Adhesive Fabric Premium, PTFE Tape/teflon adhesive with release paper

teflon adhesive with release paper

Teflon Adhesive Premium Series, high quality PTFE coated fabric

Teflon Adhesive premium series is using high quality PTFE coated fabric as basic fabric, after chemical treated one side of PTFE, it will be coated with high quality Silicone pressure adhesive, which can resist heat up to 260°C and offer long lasting performance.



Yellow textured PVC  release liner is applied to the adhesive surface for ease of application and protection long lifetime of fresh adhesive.



teflon adhesive

Teflon adhesive

Property of PTFE coated adhesive fabrics



Teflon adhesive contain non stick PTFE coated surface and heat resistant adhesive, like silicone PSA or acrylic adhesive, that allow for easy release, superior mechanical strength, long lifetime and dimensional stability.



PTFE coated tape with silicone PSA is the best solution for high request applications, which has requirement for continuous and efficient processing, excellent bonding strength and long lasting performance at high temperatures (up to 500˚F / 260˚C).



The properties of PTFE coated tape with silicone PSA is as follows.



  Excellent dimensional stability and durability in heat.

  Superior easy mold release property, excellent Non stick

  operating continuous from -73°C and +260°C

  Flame resistant

  High dielectric constant

  Good mechanical strength



Technical Data Sheet of PTFE adhesive fabric Premium Series



ProductProduct CategoryCoating
PTFE GLASS FABRIC SELF ADHESIVEPREMIUM SERIESILICONE PSA



PTFE Adhesive Fabric Premium Series
StyleStandard Width(mm)
Please ask for other widths
Backing Thickness (mm)Total Thickness (mm)Weight
(g/m2)
Adhesive
(N/cm)
Tensile Strength Warp/Fill
(N/cm)
YS7008AJ-ESONE1000, 12500.080.131554.4104/98
YS7013AJ-ESONE1000, 12500.130.182705.4240/200
YS7015AJ-ESONE10000.150.203165.6240/200
YS7018AJ-ESONE10000.180.233705.6320/302
YS7020AJ-ESONE10000.200.254105.7280/256
YS7025AJ-ESONE10000.250.305306.0460/400
YS7030AJ-ESONE10000.300.356256.2680/640



Applications of Teflon adhesive



The main applications including Package (heat-sealing, heat shrink, plastic bag manufacturing), PVC window & door welding, Plastic and polymer processing (laminating, curing, extrusion, casting, vulcanization), Wood processing and laminating, Textile, Electronics (electrical insulation, cable wrapping, FPCB manufacturing), Automotive, Aerospace(Mold release, cable wrapping) and so on.



Aircraft Composites Manufacturing

ESONE PTFE coated fabric is used in the manufacturing of composite aircraft components, like mold release tape, vacuum bagging bleeder cloths.
Mold release tape is applied directly to the mold, allowing for a clean and easy release surface. And the porous PTFE fabric provides excellent release and is used as breather fabrics, allowing for air and volatiles to escape
PTFE fabric for composite aircraft components

PTFE fabric for composite aircraft components

Wind Turbine Blades Release

This application also use PTFE porous fabric and PTFE adhesive fabric. We customize PTFE porous fabric with balanced porosity & release property, and has high mechanical strength. For PTFE adhesive fabric, our mold release tape is easy release and has high mechanical strength, so that it can be reused many times easily.
Wind Turbine Blades Release

Wind Turbine Blades Release

Automotive Composites Manufacturing

-PTFE Release sheet for lightweight plastic/polymer processing like SMC, GMT and RMT.
-PTFE Release sheet for lightweight automotive components like front ends, underbody trims, door carrier, parcel shelf and auto seat.
-PTFE Release sheet with adhesive for vehicle cord fabric lamination.
-PTFE Bleeder cloths and PTFE mold release tape for carbon fiber car hood.
Release sheet for automotive composites manufacturing

Release sheet for automotive composites manufacturing

Electrical Insulation

-Youngsun PTFE coated cloth is used for electrical insulation such as aerospace wire wrapping and electrical coil and phase insulation.
-Our PTFE Fabric has excellent mechanical strength, high dielectric constant, strong chemical resistance and heat resistant to 500°F/260°C.
-Youngsun PTFE fabrics are also used as linings for the coils of superconducting magnets in order for reducing noise and vibration.
PTFE coated fabric for electrical insulation

PTFE coated fabric for electrical insulation

FPCB CVL Lamination

Youngsun PTFE coated fabrics are used as release liner for CVL (coverlay) lamination or quick lamination, since our material has high mechanical strength and offers excellent release and non-stick property.
Excellent smooth, easy release and defect free PTFE fabric will maximum the output in FPCB manufacturing process.
PTFE release sheet for FPCB CVL Lamination

PTFE release sheet for FPCB CVL Lamination

Packaging and Sealing

Youngsun PTFE belting is used as conveyor belt to prevent polyethylene film sticking on the surface. Our belt last long, offers quick replace and easy to use.
Our belts for food packaging and sealing are available in tear resistant and porous versions for flexible packaging.
Vacuum Sealing Package

Vacuum Sealing Package

Plastic bag manufacturing

Plastic bag is heat welded by high speed for sealing, and PTFE coated fabric or PTFE self adhesive fabric is a must use release sheet in this application.
Youngsun tear resist fabric or adhesive tape is also available for this application.
PTFE fabric for plastic bag manufacturing

PTFE fabric for plastic bag manufacturing

PVC Window and Door welding

PTFE coated fiberglass cloth has excellent no stick surface and can resist heat up to 260°C, which can prevent melted PVC from sticking on welding platens. ESONE's product is workable for all kinds of welding process, including RF and microwave systems.
PVC Windows & Doors

PVC Windows & Doors

Dyeing or Printing

Due to the non stick surface of PTFE Adhesive Sheet, ESONE product is used in Dyeing industry, in order for offering heat resistant and non stick surface.
Teflon adhesive tape for Dyeing

Teflon adhesive tape for Dyeing

Flame Spray Masking Tapes

PTFE self adhesive fabric, silicone coated fiberglass, fiberglass adhesive tape is used for plasma flame spray masking application, due to the heat resistant property.
Various color is available, and any width can be cut.
Flame Spray Tapes

Flame Spray Tapes
