Double sided Polyimide Film Adhesive Tape, also referred to as double-sided Kapton tape, is made from a 0.025mm(1mil) polyimide film substrate and is coated with imported silicone pressure sensitive adhesive on both sides. With a total thickness of 0.1mm, it features either a double-sided or single-sided composite PET fluorine release liner.

This high-temperature resistant tape offers excellent insulation, wear resistance, and resistance to acids and alkalis. It can withstand temperatures of up to 280℃(536℉) for 30 minutes and can be used continuously at 260℃(500℉).

Antistatic polyimide film adhesive tape, also known as ESD Kapton Tape, ESD PI Tape, or ESD Polyimide Tape, is manufactured from a polyimide film treated for antistatic properties on both sides. This treatment utilizes proton bombardment technology in a plasma environment, achieving a static index of up to 10^5 without adding any additives or coatings, preserving the film’s original properties. The adhesive used has double the bonding strength compared to regular products.

The tape features a single-sided high-performance silicone pressure-sensitive adhesive. The surface resistance on the back is less than 10^7 ohms, while the coated surface is below 10^9 ohms. The stripping electrostatic voltage is under 50V, ensuring that electronic components remain safe from static discharge during application.

ESONE Polyimide film adhesive tape/Kapton Tape is ideal for applications that require high dielectric strength in extreme temperature conditions. These tapes provide excellent resistance to high heat, solvents, and abrasion. Our extensive range of polyimide tapes includes options with either single-sided or double-sided adhesive, available with either acrylic or silicone pressure sensitive adhesives, all specifically designed for high-temperature electrical applications.

Advantages of Polyimide Film Adhesive Tape

• Easy Peeling: Strong adhesion that leaves no residue upon removal.
• Customized Adhesion Levels: Low, medium, and strong adhesion options tailored to customer specifications.
• High-Temperature Resistance: Excellent heat insulation, ideal for protecting electronic and electrical components.
• Environmentally Friendly: Odorless with reliable electrical insulation and high voltage withstand capabilities.
• Flame Retardant: Our products comply with UL 510 flame retardance standards and meet UL94 V-0 requirements, providing enhanced safety for users in industries such as electronics, aerospace, and automotive.
• Excellent Dielectric Property: This imported film provides excellent dielectric properties, making it ideal for H-class Kapton tape electrical insulation with a 5 kV voltage withstand capability.
