PTFE Fabric Anti-static Series

PTFE fabric anti static series is coated with specially formulated black PTFE. These fabrics eliminates static electricity during operation.

Static can be created by friction or other connection, it will collect electric and dust which may destroy electrical component parts, and it will affect the release due to the electrostatic adsorption.

YouTube video

This conductive PTFE fabric offers excellent thermal conductivity to dissipate surface static, it is widely used in apparel, electron industry as conveyor belts or release sheet.

ProductProduct CategoryCoating
PTFE GLASS FABRICANTI STATIC SERIESPTFE
PTFE Fabric Anti static Series
StyleStandard Width(mm)
Please ask for other widths
Normal Thickness
(mm)
Weight
(g/m2)
PTFE Content
(%)
Tensile Strength Warp/Fill
(N/cm)
YS9008BJ-ESONE1000/12500.0815568102/98
YS9011BJ-ESONE1000/12500.1122048240/200
YS9012BJ-ESONE1000/12500.1224559240/200
YS9013BJ-ESONE1000/1250/15000.1328060240/200
YS9018BJ-ESONE1000/1250/15000.1837055320/305
YS9023BJ-ESONE1000/1250/1500/2000/26000.2350060420/360
YS9025BJ-ESONE1000/1250/1500/2000/26000.2553062460/400
YS9035BJ-ESONE1000/1250/1500/2000/26000.3568062540/508
YS9037BJ-ESONE1000/1250/1500/2000/26000.3773060540/508
YS9090B-ESONE1500, 1600, 22500.901650511240/1180
YS9038HS-ESONE15000.38560For Insulation Jacket
