Teflon Adhesive Sheet YS7012AJ

Teflon Adhesive Sheet YS7012AJ

Teflon Adhesive Sheet YS7012AJ, PTFE adhesive fabric Industrial Series

Teflon adhesive sheet is using PTFE coated fiberglass fabric as basic material, and coated with silicone pressure adhesive(PSA). This tape has easy release surface and cost-effective property, widely used in Packaging, plastic bag sealing, wire and cable insulation, LCD/FPCB/PCB bonding release, laminating of PVC window and so on.



Teflon Adhesive Sheet YS7008AJ

Teflon Adhesive Sheet YS7008AJ

Properties of Teflon adhesive sheet



   Good release property

Coated with medium level of PTFE, YS7012AJ has good release property to ensure non stick property



   High working temperature

PTFE adhesive fabric can continuous working under 260 C degrees.



   Adhesion can be customized

ESONE can customize the adhesion that customer need, it could be high or less, strong initial or weak initial, easy to peel off or difficult to peel off.



   Cost effective

With medium PTFE coating, this PTFE tape can show good property with lower cost.



High temperature Teflon tape

High temperature Teflon tape



Technical Data Sheet of YS7012AJ PTFE adhesive fabric



ProductProduct CategoryCoating
PTFE GLASS FABRIC SELF ADHESIVEINDUSTRIAL SERIESSILICONE PSA



PropertiesMetricImperial
Standard width
Please ask for other widths
1000, 1250 mm39.5, 49.3 inches
Backing Thickness
PTFE glass
0.12 mm0.0047 inches
Total Thickness
PTFE glass and adhesive
0.17 mm0.0067 inches
Baking weight
PTFE glass
250 g/m² 7.37 oz/yd²
Tensile Stength
PTFE glass
235 N/cm Warp134 lbs/inches Warp
215 N/cm Fill123 lbs/inches Fill
Adhesion5.8 N/cm52.6 oz/inches
Temperature resistance-73 to +260 °C-100 to +500 °F



Click here to download the TDS of YS7012AJ-ESONE



Color available: Brown, Black, White

For samples of Teflon Adhesive Sheet,  please feel free to contact us.



Tear Resistant Teflon coated Tape

Tear Resistant Teflon coated Tape



Note:
Thickness Tolerance mm= ±%5
All technical data are based on average values. These values are based on test results we believes to be reliable, but they are not to be constructed in any manner as warranties expressed.
