PTFE Tear Resistant Fabric

/, PTFE Tear Resistant Fabric/PTFE Tear Resistant Fabric

PTFE Tear Resistant Fabric

PTFE Tear Resistant Fabric, increased tear and crease strength property.

PTFE Tear Resistant Fabric, by coating with specially formulated Teflon(PTFE), the tensile strength, tear strength and crease strength all got improved. This Tear resistant fabric is designed for aerospace industry, packaging industry, food processing industry, Tortilla production industry, PVC door & window welding industry and so on.



PTFE Tear Resistant Fabric

PTFE Tear Resistant Fabric



Why use PTFE  Tear Resistant Fabric



PTFE Tear Resistant Cloth is produced for applications in tough working environment, like continuous high pressure and high temperature, or used for minimize the downtime of machines, ensure the quality of processed product.

PTFE Tear Resistant Fabric is typically used in applications requiring high-flex properties or belting applications with small diameter pulleys.



Teflon coated fiberglass fabric

Teflon coated fiberglass fabric



For aerospace industry, PTFE Tear Resistant Cloth is used to resist the high pressure during curing and laminating, also offers the non stick surface.

For packaging industry and food processing industry, PTFE Tear Resistant Fabrics is designed for increasing the lifetime of release sheet, and guarantee the quality of the processed product.

For Tortilla production, in order to resist the continuous pressure, high temperature and oil leaking, PTFE fabric will be requested to have an abrasion resistant, tear resistant property, and a smooth surface without pin holes.



Property of Teflon Tear Resistant Fabric



  Superior non-stick surface, easy to release and clean
  Outstanding temperature resistance (continuous working from -170°C to +260°C)
  Non-toxic and compliant for food applications, FDA & LFGB certificated
  Strong resistance to almost all chemicals
  Excellent dimensional stability, strong tensile strength and tear strength
  Flexibility
  High electrical insulating power, strong resistance to electric arc
  Resistance to microwaves, UV and RF and HF.



Technical Data Sheet of PTFE Tear Resistant Cloth



ProductProduct CategoryCoating
PTFE GLASS FABRICTEAR RESISTANT SERIESPTFE



PTFE Fabric Tear Resistant Series
StyleStandard Width(mm)
Please ask for other widths
Normal Thickness
(mm)
Weight
(g/m2)
PTFE Content
(%)
Tensile Strength Warp/Fill
(N/cm)
YS9008AT-ESONE10000.07513564190/180
YS9011AT-ESONE10000.11523554240/230
YS9014AT-ESONE1000, 1250, 15000.1425557360/330
YS9015AT-ESONE10000.1529563360/330
YS9023AT-ESONE10000.2349059560/540



Anti static (conductive) PTFE tear resistant Fabric is also available.



4 Comments

  1. William 2018年7月25日 at am8:23 - Reply

    Why these PTFE fabric is stronger than normal fabric, is it using different material?

    • Ms. PTFE 2018年7月25日 at am9:36 - Reply

      Hi William, thanks for your comment!
      Yes, we are using stronger fiberglass yarn for stronger tensile strength, and special PTFE formula also.
      This PTFE tear resistant fabric is designed for aerospace, packaging, tortilla industry and so on, and this fabric can be used as reinforcement for belt or sheet.

  2. Duane Small 2022年3月10日 at am8:22 - Reply

    Is this material appropriate for use with chlorinated water.

    • Mr. PTFE 2022年3月13日 at pm12:57 - Reply

      Hi Duane, yes, it is fine to work with chlorinated water
