Teflon Tape YS7020AJ

Teflon Tape YS7020AJ

Teflon Tape YS7020AJ, PTFE adhesive fabric Premium Series

Teflon tape YS7020AJ is using YS9020AJ as basic material (PTFE content is 60%), and coated with high quality silicone PSA on the back, which ensure heat resistant to 260°C and long lasting performance.

The yellow PVC liner on the back, is used to protect the adhesive and for ease of application.



Teflon Tape

Teflon Tape



Description of Teflon tape



PTFE(Teflon) is a high-molecular-weight compound consist of only Carbon and Fluorine. It is hydrophobic: neither water nor water-containing substances wet PTFE, as fluorocarbons demonstrate mitigated dispersion forces because of high electronegativity of fluorine. Compared to any solid, PTFE has the lowest coefficients.

With these characteristics, PTFE can be used a lot for nonstick coating on fiberglass, metal, plastics and other substances, such as making Teflon tape.



Teflon Tape is made of PTFE coated glassfiber fabrics, which has super nonstick surface and high temperature resistance

Teflon Tape is made of PTFE coated glassfiber fabrics, which has super nonstick surface and high temperature resistance

Application of Teflon adhesive tape



Due to the super nonstick surface and high temperature resistant, Teflon Tapes are workable for applications which need to resist continuous high temperature, high corrosivity or high electric strength.

For plastic bag sealing process as an example, when hot-sealing opp bags, we need PTFE tape to resist temperature and also prevent plastics sticks on the metal.



PTFE tape for polybag manufacturing

PTFE tape for polybag manufacturing



Technical Data Sheet of YS7020AJ PTFE adhesive sheet



ProductProduct CategoryCoating
PTFE GLASS FABRIC SELF ADHESIVEPREMIUM SERIESILICONE PSA



PropertiesMetricImperial
Standard width
Please ask for other widths
1000 mm39.5 inches
Backing Thickness
PTFE glass
0.20 mm0.0079 inches
Total Thickness
PTFE glass and Silicone PSA
0.25mm0.0099 inches
Coated weight
PTFE glass
410 g/m² 12.1 oz/yd²
Tensile Strength
PTFE glass
280 N/cm Warp160 lbs/inches Warp
256 N/cm Warp146 lbs/inches Warp
Adhesion5.7 N/cm52 oz/inches
Temperature resistance-73 to +260 °C-100 to +500 °F



Click here to download the TDS of YS7020AJ-ESONE

Click here to access PTFE acrylic adhesive tape



Teflon Tape for packing industry

ptfe adhesive tape for packing industry
