PTFE Fiberglass YS9013AJ

PTFE Fiberglass YS9013AJ

PTFE Fiberglass, high glossy and easy release

PTFE Fiberglass is called as PTFE coated fiberglass fabric, basic material is high quality E-Glass, impregnated with high performance PTFE content to produce high glossy, extreme smooth coating.

In order for offering high quality and premier series PTFE Fiberglass, Youngsun will add special reliable material to modify PTFE property.


PTFE Fiberglass

PTFE Fiberglass


Choosing high quality E-Glass for PTFE Fiberglass Premier Series


1)  Weaved fiberglass will provide excellent mechanical strength for PTFE Fiberglass, such as tensile strength in fill or warp and tear strength. This will affect the lifetime directly, especially in working environment with high temperature and strong pressure.

2) High quality fiberglass will prevent Teflon Fiberglass from breakage, fall apart, tear and so on.

3) And the surface of the fiberglass will effect the surface of PTFE glass fiber directly, good fiberglass will result in a super smooth surface of PTFE coated fiberglass.


Coating high quality PTFE for PTFE Fiberglass Premier Series


1) High quality PTFE will combine with fiberglass tightly, after laminating many times, the PTFE will still never peel from fiberglass.

2) Imported PTFE like Daikin and Dupont is PFOA free, which can be used to touch food directly, making into belting for food, Non stick oven liner or baking liner, Non stick BBQ mat and so on.

3) High quality PTFE will result in a excellent smooth surface, no defect such as crack, drape and so on. It will also reduce the pin holes on the surface. Easy release in the processing.


Characteristics of PTFE Fiberglass


  Non-stick surface, easy release, low friction

  Working continuous from -73°C – +260°C

  Chemical resistant and environmental resistant

  High tensile strength and dimensional stability

  Reusable and has long lifetime


Technical Data of Teflon coated Fiberglass Fabric


ProductProduct CategoryCoating


Standard width
Please ask for other widths
1000, 1250, 1500 mm39.5, 49.3, 59.1 inches
Thickness0.13 mm0.0051 inches
Coated weight270 g/m² 7.96 oz/yd²
PTFE content60 %60 %
Tensile strength240 N/cm Warp137 lbs/inches Warp
200 N/cm Fill114 lbs/inches Fill
Temperature resistance-73 to +260 °C-100 to +500 °F


Click here to download Spec of YS9013AJ-ESONE


For samples of PTFE Fiberglass,  please feel free to contact us.

Weight Tolerance g/m² = ±%5
All technical data are based on average values. These values are based on test results we believes to be reliable, but they are not to be constured in any manner as warranties expressed.


PTFE coating fiberglass

PTFE coating fiberglass


  1. Chula 2018年7月18日 at am11:44 - Reply

    one of our machine required a belt which has following dimension
    thickness 130
    width 1000mm and 2564mm

    • ptfef1c8 2018年7月19日 at am10:08 - Reply

      Hi Chula, thanks for your comments.
      We are manufacturer of PTFE fabric, and we also make it into belt, sheet and so on.
      Our sales team will contact with you soon:)

  2. Jeff 2018年8月23日 at am7:35 - Reply

    Please send price of 1500mm wide YS9013AJ

    • Ms. PTFE 2018年8月23日 at am8:42 - Reply

      Hi Jeff, thanks for your comment.
      The standard width for YS9013AJ is 1000mm or 1250mm, if you need 1500mm wide, then the price will be different.
      Our sales team will contact with you soon!
