Adhesive Backed Teflon Sheet YS7013AJ

/, PTFE Adhesive, PTFE Adhesive Fabric Premium, PTFE Tape/Adhesive Backed Teflon Sheet YS7013AJ

Adhesive Backed Teflon Sheet YS7013AJ

Adhesive Backed Teflon Sheet YS7013AJ, the best selling Teflon tape

Adhesive backed Teflon sheet is widely used in aerospace, automotive, electronic, energy, food processing, packaging, plastic and polymer production, textile, PVC window and so on.

And YS7013AJ is the best selling PTFE adhesive tape, since it can offer great release with reasonable cost, and is workable for almost all kinds of applications.

Adhesive Backed Teflon Sheet

Adhesive Backed Teflon Sheet



Adhesive Backed Teflon Sheet is a combination of Teflon, fiberglass and silicone PSA, which allows sheet to perform in continuous high temperatures.



Properties of PTFE Teflon Adhesive Tape



★  Easy release and long lasting

With high PTFE content, good mechanical strength and abrasion resistant, ESONE Teflon adhesive sheet has easy release surface and can perform long time.



★  Continuous working below 260 C degrees

Adhesive Backed Teflon Sheet is a heat resistant release fabric, can continuous working below 260 C degrees, and offer reliable release property in high temperature.



Teflon adhesive sheet

Teflon adhesive sheet



★  High mechanical strength

In order for working continuously under high pressure in applications such as lamination, vacuum bagging system, ESONE High temp Teflon tape has high mechanical strength and dimensional stability to resist high pressure in process.



★  Good dielectric strength

Teflon coated fiberglass tape has strong dielectric strength, so Teflon tape is widely used in cable wrapping insulation, CCL(copper clad laminate) production, FPCB CVL lamination and so on.



Technical Data Sheet Teflon adhesive YS7013AJ



ProductProduct CategoryCoating
PTFE GLASS FABRIC SELF ADHESIVEPREMIUM SERIESILICONE PSA



PropertiesMetricImperial
Standard width
Please ask for other widths
1000, 1250 mm39.5, 49.3 inches
Backing Thickness
PTFE glass
0.13 mm0.0051 inches
Total Thickness
PTFE glass and Silicone PSA
0.18 mm0.0071 inches
Baking weight
PTFE glass
270 g/m² 7.96 oz/yd²
Tensile Strength
PTFE glass
240 N/cm Warp137 lbs/inches Warp
200 N/cm Fill114 lbs/inches Fill
Adhesion5.4 N/5cm49 oz/inches
Temperature resistance-73 to +260 °C-94 to +500 °F



Click here to download the TDS of Self Adhesive Teflon Tape YS7013AJ-ESONE

The color can be Dark brown, Light brown, Black or white.

For samples of Adhesive Backed Teflon Sheet,  please feel free to contact us.
