Teflon tape adhesive YS7010W

Teflon tape adhesive YS7010W

Teflon tape adhesive industrial series, has easy release surface and cost-effective property.

Teflon tape adhesive YS7010W is using PTFE fabric industrial series as basic material, and coated with silicone pressure adhesive. This tape has good release surface and cost-effective property, widely used in Packaging, polybag sealing, wire and cable insulation, LCD/FPCB/PCB bonding release, laminating of PVC window and so on.



Teflon tape adhesive YS7010W White

Teflon tape adhesive YS7010W White



Composition of Teflon tape adhesive



The basic material of Teflon adhesive sheet is PTFE coated fiberglass fabric, which has non stick and chemical resistant property. In this case, in order to coat silicone PSA on the back, the PTFE fabric must be treated on one side.

After treated, PTFE fabric will be coated with Silicone PSA by horizontal coating machine, and protected by yellow release liner.



Property of self adhesive PTFE tape



   Good release(non stick)

Coated with medium level of PTFE, YS7010W has good release property to ensure non stick property.



   High working temperature

PTFE adhesive tape can continuous working under 260 C degrees.



   Adhesion can be customized

ESONE can customize the adhesion that customer need, it could be high or less, strong initial or weak initial, easy to peel off or difficult to peel off.



   Cost effective

With medium PTFE coating, this PTFE tape can show good property with lower cost.



ESONE PTFE Adhesive Tape

ESONE PTFE Adhesive Tape



Advantages of PTFE adhesive tape industrial series



Packaging and food processing industry has a big quantity demand for the PTFE adhesive tape, and since the working temperature is not high, the working environment is not tough, so the request for the PTFE adhesive tape is not high.

In this case, we offer PTFE industrial adhesive tape for different industry. This tape will offer good property and reasonable cost.



Technical data sheet of Teflon adhesive tape



ProductProduct CategoryCoating
PTFE GLASS FABRIC SELF ADHESIVEINDUSTRIAL SERIESSILICONE PSA



PropertiesMetricImperial
ColorWhiteWhite
Standard width
Please ask for other widths
1000, 1250 mm39.5, 49.3 inches
Backing Thickness
PTFE glass
0.10 mm0.0039 inches
Total Thickness
PTFE glass and adhesive
0.15 mm0.0049 inches
Baking weight
PTFE glass
200 g/m² 5.9 oz/yd²
Tensile Stength
PTFE glass
240 N/cm Warp137 lbs/inches Warp
200 N/cm Fill114 lbs/inches Fill
ColorBlackBlack
Adhesion5.4 N/cm49 oz/inches
Temperature resistance-73 to +260 °C-100 to +500 °F



Click here to download the TDS of Teflon tape adhesive YS7010W-ESONE

ptfe teflon adhesive tape

PTFE Teflon Adhesive Tape is produced from PTFE impregnated glass fabric that are coated with a high-temperature-resisntant silicone adhesive.
